DESIGN OF A BUILDING DESIGN, MODELING, AND INFORMATION (DPIB) LABORATORY AS A LEARNING FACILITY AT SMK NEGERI 5 PADANG
DOI:
10.5281/zenodo.21723801Published:
2026-07-31Downloads
Abstract
The availability of a laboratory that supports the characteristics of practical learning is an important factor in developing students’ competencies in Building Design, Modeling, and Information (DPIB). This community service activity aimed to develop a functional and comfortable DPIB laboratory design at SMK Negeri 5 Padang to support technology-based learning. The activity employed a participatory and user-centered design approach through several stages, including existing-condition observation, identification of partner needs, conceptual design, design development, validation, and finalization. The activity resulted in a laboratory design with an area of approximately 270 m², integrating a planning and model-making practice area, instructor room, computer-based design practice area, circulation system, lighting, ventilation, electrical facilities, and digital learning support. The proposed design provides the school with a technical reference for developing a more structured DPIB laboratory that is aligned with the needs of vocational learning.
Keywords:
DPIB laboratory facility design vocational learning BIM vocational high schoolReferences
Aryanti, F. N., Busono, R. R. T., & Siswoyo, S. (2020). Implementation of Building Information Modelling (BIM) Revit to meet the needs of the construction industry. IOP Conference Series: Materials Science and Engineering, 830, Article 042054. https://doi.org/10.1088/1757-899X/830/4/042054
Badan Standar, Kurikulum, dan Asesmen Pendidikan. (2022). Capaian pembelajaran mata pelajaran Desain Pemodelan dan Informasi Bangunan Fase F untuk SMK/MAK [Learning outcomes for the Building Design, Modeling, and Information subject, Phase F, for vocational high schools]. Kementerian Pendidikan, Kebudayaan, Riset, dan Teknologi Republik Indonesia.
Ching, F. D. K. (2023). Architecture: Form, space, and order (5th ed.). John Wiley & Sons.
Guo, B. H. W., Gonzalez, V. A., Puolitaival, T., Enegbuma, W., & Zou, Y. (2023). Bridging the gap between Building Information Modelling education and practice: A competency-based education perspective. International Journal of Construction Management, 23(15), 2558–2569. https://doi.org/10.1080/15623599.2022.2077546
International Organization for Standardization. (2019). Ergonomics of human-system interaction—Part 210: Human-centred design for interactive systems (ISO Standard No. 9241-210:2019; 2nd ed.).
Irvansyah, Muchlis, N., & Suryawan, W. A. (2024). Analysis of the BIM implementation competencies of building cluster vocational high school students in East Java. Border: Jurnal Arsitektur, 4(2), 95–108. https://doi.org/10.33005/border.v4i2.122
Lius, J. F., Oktiarso, T., & Putrianto, N. K. (2022). Usulan perbaikan laboratorium komputer Universitas Ma Chung pada aspek suhu dan pencahayaan dengan pendekatan ergonomi partisipatori [Proposed improvements to the Ma Chung University computer laboratory regarding temperature and lighting using a participatory ergonomics approach]. Jurnal Sains dan Aplikasi Keilmuan Teknik Industri (SAKTI), 2(2), 101–112. https://doi.org/10.33479/jtiumc.v2i2.32
Murtinugraha, R. E., Ramadhan, M. A., & Andarista, P. L. (2021). Kesesuaian standar sarana prasarana SMK kompetensi keahlian Desain Pemodelan dan Informasi Bangunan: Studi pada SMKN 56 Jakarta dan SMKN 35 Jakarta [Conformity with vocational high school facility and infrastructure standards for the Building Design, Modeling, and Information competency program]. Jurnal Pendidikan Teknik Sipil, 3(1), 1–10. https://doi.org/10.21831/jpts.v3i1.41881
Neufert, E., Neufert, P., & Kister, J. (2019). Architects’ data (5th ed.). Wiley-Blackwell.
Sucipto, T. L. A., Sajidan, Akhyar, M., & Roemintoyo. (2024). Investigating Building Information Modelling (BIM) adoption in vocational high school learning. In Proceedings of the 5th Vocational Education International Conference (VEIC-5 2023) (pp. 1096–1101). Atlantis Press. https://doi.org/10.2991/978-2-38476-198-2_155
Telaga, A. S. (2022). A lesson learned from the integration of BIM in construction engineering education in an Indonesian polytechnic. Jurnal Pendidikan Vokasi, 12(2), 130–140. https://doi.org/10.21831/jpv.v12i2.48455
